AR-50 Automatic Single-side labelling machine
Original price was: R235 000.00.R198 000.00Current price is: R198 000.00. ex. VAT
Available on backorder
Available on backorder
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Specification
Overview
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Processor
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Display
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
RAM
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Storage
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Video Card
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Connectivity
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Features
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Battery
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
General
| Weight | 150 kg |
|---|---|
| Dimensions | 260 × 160 × 160 cm |
Description
Feature and description of the machine
AR-50 Automatic Single-side labelling machine is suitable to the medicine, the date, food industry etc cylindrical container or smaller conical taper container of ChanBiao, Single standard automatic positioning labelling. This machine is very reliable and well priced.
Can be equipped with all kinds of printer option add on’s. Can be connected to a Product line.
1、The step or the servo motor system.
2、Clutch design, make the label tension force more reliable, and easy to improve labelling position.
3、Advanced colour man-machine interface control system.
4、Germany Siemens PLC control, high reliability.
5、Use Germany, Japan magic eye.
6、Machine structure is simple, compact, easy to operation and maintenance.
7、Can add ribbon typewriter, or heat transfer machine and automatic send bottle opener (optional).
Technical Parameter:
(AR50)FULLY AUTO)
LABEL APPLICATOR OFF PRINTED ROLL 75-76mm,
3000BPH, 10-60 pcs/min pcs/min /
PRODUCT SIZE: 30mm – 100mm
(label size min: L30XW20, max: L200XW150)
| Model | AD-50 |
| Label width | 20-180mm |
| Label length | 20-200mm |
| Product range | L: 20mm～200mm W：20mm～150mm H：30mm～100mm |
| The outer diameter of the label roll | ≤Φ200mm |
| The core diameter of the label roll | φ76mm |
| Speed | 10-60 pcs/min |
| Accuracy | ±1mm |
| Machine size (L *W* H) | 2500*1600*1600 |
| Machine weight | 150kg |
